How to Use Codex to Create dbt Models

📘 Introduction

Codex can be very useful in a dbt project, especially when you already have a clean Silver layer and want to create a business-ready Gold model from it. Instead of starting from an empty prompt, you can give Codex the current project structure, the existing models, and the exact output you want.

In this tutorial, you will learn how to use Codex to create a dbt Gold model. We will use the Medallion Architecture in dbt for this example, where data moves from cleaned Silver models into a business-ready Gold model: two Silver models already exist, and Codex will help us create a Gold dimension model named dim_course.

💡 What are we implementing?

We start with two existing Silver models:

• course_cleaned contains cleaned course facts such as id, code, credits, level, semester_number, and source_name.
• course_mapping_cleaned contains descriptive course information such as code and name.

Codex will generate a Gold model that joins both models and creates a simple course dimension:

Silver course_cleaned + Silver course_mapping_cleaned -> Codex -> Gold dim_course

The important part is that Codex should not guess the business logic. We will tell it the model name, the input models, the join key, the expected grain, and the columns we want in the final output.

✅ Prerequisites

☑️ A working dbt project with a Silver layer
☑️ The Silver models course_cleaned and course_mapping_cleaned already exist
☑️ Codex is available in the Codex app, CLI, or IDE extension
☑️ Basic knowledge of SQL and dbt models
☑️ A Git workflow where you can review changes before committing them

🧭 Current project state

Before asking Codex to create anything, make the current state of the project clear. In our example, this excerpt of the project already contains the Silver layer, but the Gold layer is still empty.

models/
├── silver/
│   ├── course_cleaned.sql
│   └── course_mapping_cleaned.sql
└── gold/

This is a useful point to pause and define what the Gold layer should do. In a Medallion Architecture, Silver models are cleaned and standardized, while Gold models are shaped for reporting, analytics, or business-facing use cases.
